Commander® E6013 is a high-performance general-purpose mild steel welding electrode manufactured as per AWS/SFA 5.1: E6013 and IS 814: ER4211X classification standards. Designed for versatile welding operations, this electrode provides reliable performance with excellent arc stability, medium penetration, and superior weld quality.
Its easy striking characteristics, smooth arc control, low spatter generation, and detachable slag make it ideal for both professional welders and industrial applications. Commander® electrodes provide consistent weld deposits with good mechanical properties, making them suitable for welding mild steel structures where strength and finish are important.
Applications:
- Mild steel fabrication work
- Plate welding and structural welding
- Pipes and flanges
- Tubular section frames
- Steel furniture and window grills
- Textile machinery components
- General repair and maintenance work
Key Features:
- AWS E6013 classification
- All-position welding capability
- Stable and smooth arc performance
- Medium penetration for controlled welding
- Low spatter generation
- Easy slag removal
- Smooth and clean weld bead
- Excellent mechanical properties
- Suitable for low current welding
Mechanical Properties:
- Ultimate Tensile Strength: 430 MPa Min
- Yield Stress: 330 MPa Min
- Elongation: 22% Min
- Reduction in Area: 50% Min
- Charpy Impact Value: 47J Min at 0°C
Available Sizes:
- 2.50 mm × 350 mm (60–90 Amps)
- 3.15 mm × 450 mm (90–130 Amps)
- 4.00 mm × 450 mm (130–180 Amps)
- 5.00 mm × 450 mm (180–220 Amps)
Redrying Temperature: 150°C for 1 hour
